High color rendering LED light source box (A3 size)–VLB-4230FBW3-CRI

  • High color rendering LED Ra=97
  • Can attach both chart holders ;aspect ratio 4:3 and 16:9
  • High uniform wide luminance ranges on the surface of light box
  • Fine tuning of luminance
  • 2 types of color temperatures
  • Auto calibration with separated sold luminance meter (LC-5)
  • Multiple options

View the product in 3D
(There may be parts that are different from the actual product or parts that are not displayed due to capacity reasons)

WP 3D Thingviewer need Javascript to work.
Please activate and reload the page.

Bookmark

Model VLB-4230FBW3-CRI
Luminance [LV] 7.0-14.0 /programmed brightness points; 10 points
Luminance [cd/㎡] 20-2300 /programmed brightness points; 10 points
Luminance surface (WxH) [mm] 420x300
Luminance unevenness [± %] 2.5
Correlated color temperature [K] Choose 2 types from below
3200+/-150
5500+/-500
6500+/-500
Light source LED
Lighting method PWM 100[kHz]
function Change entered luminance
Adjust luminance
Luminance feedback function
Switch entered color temperatures
LED OFF
Auto calibration (connecting LC-5)
Display / Operation Operation unit of the main part
External communication control (serial communication)
Communication I / F USB2.0
Power-supply voltage AC100-240V 50/60Hz
Power consumption [VA] 100
