Near infrared LED surface light source– LSB-8IR-Series

Catalog Download

  • High uniformity surface light source with NIR wavelengths
  • Suitable for chart evaluations or production process
  • Adjust an intensity of infrared
  • Non-flicker by DC lighting method
  • Select a wavelength from; λ[nm]=780, 850, 860, 905, 910, 940, 950, 1050, 1060, 1300, 1450, 1550, etc.

Bookmark

Model LSB-8IR-Series
Luminance surface (WxH) [mm] 80×80
Intensity unevenness [± %] 2.5
Light source LED
Lighting method DC
Wavelength [nm] Select one wavelength from the below [nm]
780, 850, 860, 905, 910, 940, 950, 1050, 1060, 1300, 1450, 1550
Intensity [μW/㎠] Depending on a select wavelength
function Adjust intensity of infrared function
Display / Operation Operation unit of the main part
Power-supply voltage AC100-240V 50/60Hz
Power consumption [VA] Depending on a select wavelength
Operating environment Temperature: 10-40[℃] use within +/-2[℃]
Humidity: less than 80[%] without dew condensation
Dimensions (WxHxD) [mm] 120x72x120
Weight [g] 400
Extension Set multiple wavelengths
Change luminance surface size
Intensity of infrared feedback function
External communication control
Auto calibration
