- This surface light box has luminance feedback function for the stable luminance, can switch color temperatures
- Color temperatures are changed by electric powered with a switch
- Change luminance with the specified pitch and select specific luminance with the key pad or the external communication control
- Memorize & invoke luminance and color temperature; easy to change the checking sequence
Halogen Light Source Box– LSB-111BAT2
| Luminance [LV] | 2850K: 4.0-17.0 4870K: 4.0-14.5 |
|---|---|
| Luminance [cd/㎡] | 2850K: 2.5-18,000 4870K: 2.5-3,200 |
| Luminance surface (WxH) [mm] | 100x100 |
| Active luminance surface (WxH) [mm] | φ100 |
| Correlated color temperature [K] | 2850 +/- 100 4870 +/- 150 (Color temperature can be selected) |
| Light source | Halogen |
| Lighting method | DC |
| Function | Arbitrary luminance setting Changing entered luminance Luminance feedback function Switch entered color temperatures Auto Calibration (with LC-5) |
| Display / Operation | Operation of the main part External communication control (serial) |
| Communication I / F | RS-232C |
| Power-supply voltage | AC100-240V 50/60Hz |
| Power consumption [VA] | 480 |
| Operating environment | Temperature: 5-40[℃] Humidity: less than 80[%] without dew condensation |
| Dimension (WxHxD) [mm] | 367x306x426 |
| Weight [kg] | 16.5 |
| Extension function | Change the communication interface (RS-232C) to USB2.0 type-B |
